PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Support Frame 1
2 Main Frame 1
3 Stabilizer Frame 1
4 Handle 1
5 Swing Frame 1
6 Weight Holder 1
7 Seat Adjustment Frame 1
8 Rubber Bumper 1
9 Seat Pad 1
10 Arm Pad 1
11 Spring 1
12 Selector 1
13 Bushing 1
14 Bearing 4
15
∅
2 1/8” Washer 1
16 M10 x ¾” Allen Bolt 2
17 Spring Clip Sleeve 2
18 Spring Clip 1
19 Olympic Sleeve End Cap 1
20 Olympic Sleeve 1
21 M8 Screw 1
22 Roll Pin 1
23 Adjustment Plate 1
24 1 ¾” End Cap 1
25 2” End Cap 2
26 T-shaped Pull Pin 1
27
∅
1 3/8” Washer 1
28 M6 x 1 ½” Philip Screw 1
29
∅
½” Washer 2
30 Lever Knob 1
31 M10 Aircraft Nut 6
32
∅
¾” Washer 8
33 M6 Aircraft Nut 1
34 M6 Allen Bolt 1
35 U-shaped Bracket 1
36 M10 x 2 ¾” Allen Bolt 2
37 Lock Knob 1
38 Sleeve 1
39 M8 x 1 3/8” Allen Bolt 4
40 2” x 2 ¾” Horse Shoe End Cap 3
41 M10 x 1” Round Allen Bolt 4
42 Handle Grip 2
43 2” x 2” Horse Shoe End Cap 1
44
∅
5/8” Washer 4
45
∅
1 ½” Plastic Spacer 2
46
∅
2” Washer 1
47 M10 x 3 ½” Carriage Bolt 2
48 M10 x 2 ¾” Carriage Bolt 2
