Intel ENTERPRISE PRINTING SYSTEM (EPS) 4112 User Manual
Page 7
- 7 -
GA-945GCM-S2L/GA-945GCM-S2C Motherboard Layout
KB_MS
CPU_FAN
LGA775
ATX
GA-945GCM-S2L/GA-945GCM-S2C
F_AUDIO
SYS_FAN
PCIE_16
IDE
BAT
IT8718
ATX_12V
Intel
®
945GC
USB
LAN
AUDIO
LPT
R_USB
COMA
CLR_CMOS
FDD
DDRII1
DDRII2
RTL8111C
RTL8101E
VGA
Intel
®
ICH7
SATAII0
F_PANEL
PWR_LED
SATAII1
CI
CD_IN
F_USB1
CODEC
SPDIF_O
MBIOS
PCI1
PCI2
F_USB2
PCIE_1
SATAII2
SATAII3
Only for GA-945GCM-S2L.
Only for GA-945GCM-S2C.
