GA-945GCM-S2L/S2C Motherboard - 48 -
2-9 Frequency/Voltage Control
CPU Clock Ratio (Note)
Allows you to alter the clock ratio for the installed CPU.
The item is present only if a CPU with unlocked clock ratio is installed.
O.C FSB1333 Core 2 CPU
Enable use of a Core TM 2 CPU with 1333 MHz FSB through overclocking. You must install the
FSB 1333 MHz Core TM 2 CPU with DDR2 533 (or above) memory module(s).
Auto Set this item to Auto. Then save the changes and restart your computer.
During the POST, a message will appear asking if you want to enable the use
of a FSB 1333 Core
TM 2 processor. Press to confirm or to reject. Or
press any key to continue the POST. (Default value)
Disabled Disable this function.
Enabled Enable this function.
CPU Host Clock Control
Enables or disables the control of CPU host clock. Enabled will allow the CPU Host Frequency
item below to be configurable. Note: If your system fails to boot after overclocking, please wait for
20 seconds to allow for automated system reboot, or clear the CMOS values to reset the board to
default values. (Default: Disabled)
(Note) This item appears only if you install a CPU that supports this feature.
Incorrectly doing overclock/overvoltage may result in damage to CPU, chipset, or memory
and reduce the useful life of these components. This page is for advanced users only and
we recommend you not to alter the default settings to prevent system instability or other
unexpected results. (Inadequately altering the settings may result in system's failure to
boot. If this occurs, clear the CMOS values and reset the board to default values.)
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
Frequency/Voltage Control
CPU Clock Ratio (Note) [18X]
O.C FSB1333 Core. 2 CPU [Auto]
CPU Host Clock Control [Disabled]
x CPU Host Frequency(Mhz) 200
PCI Express Frequency (Mhz) [Auto]
System Memory Multiplier [Auto]
Memory Frequency (Mhz) 533
DIMM OverVoltage Control [Normal]
FSB OverVoltage Control [Normal]
CPU Voltage Control [Normal]
Normal CPU Vcore 1.38750V
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
