1-28
English-27
English
Selects the image flipping or rotation.
NORMAL: Normal display.
H MIRROR: Mirror image for horizontal direction.
V MIRROR: Mirror image for vertical direction.
ROTATE: Rotate the image 180 degrees.
Change the display area of the image.
OVERSCAN: Set to display area about 95%
UNDERSCAN: Set to display area about 100%
Selects IP (Interlace to Progressive) converter function.
PROGRESSIVE: Enable the IP function, to convert
interlace signal to progressive. Normally use this setting.
INTERLACE: Disable the IP function.
NOTE: This mode is better suited for motional pictures,
but it is in danger of image retention.
Select Film mode function.
AUTO: Enable the Film mode function. This mode is
better suited for movies, which is converted 24 Frames/
sec source to DVD Video. We recommend to select
“PROGRESSIVE” in “SCAN CONVERSION”.
OFF: Disable the Film mode function. This mode is
better suited for Broadcasting or VCR source.
Set the Monitor ID number to control the daisy
chained multiple MDT402S / MDT461S with RS-232C.
The Monitor ID number is selectable between 1 and 26.
Selects the infrared wireless remote controller mode
with using the RS-232C daisy chain.
The item in this menu will become effective by pressing
“SET” button on the selected item.
NORMAL: The monitor will be controlled normally by
wireless remote controller.
PRIMARY: Set “PRIMARY” at the head of the daisy
chained monitors by RS-232C.
SECONDARY: Set “SECONDARY” after 2nd daisy
chained monitor.
LOCK: Disable the monitor control by infrared wireless
remote controller.
Keep pressing “DISPLAY” button during 5 sec or more,
this setting will return to “NORMAL”.
TILIN G demonstrates multiple screens. This feature
provides a single large screen using up to 25 monitors.
It will be able to divide up to 5 each H and V.
This requires you to feed the PC output into each of the
monitors through a distributor.
Do not use MDT402S and MDT461S together for
TILING.
H MONITORS: Select number of horizontal divide.
V MONITORS: Select number of vertical divide.
POSITION: Select a position to expand the screen.
Frame compensation: Works in tandem with TILIN G
to compensate for the width of the tile bezels in order to
accurately display the image.
ENABLE: Select “YES”, the monitor will expand the
selected position.
PIP, POP, SIDE by SIDE and STILL and “DYNAMIC”
ZOOM mode will be disabled when “TILING” is activated.
:RETURN MENU :EXIT MENU
MONITOR ID
ID No. 1
+ -: SEL EXIT
ADVANCED OPTION
S-VIDEO MODE
BLACK LEVEL EXPANSION
GAMMA SELECTION
IMAGE FLIP
SCAN MODE
SCAN CONVERSION
FILM MODE
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT :RETURN MENU :EXIT MENU
IMAGE FLIP
:SEL
NORMAL
H MIRROR
V MIRROR
ROTATE
EXIT
ADVANCED OPTION
S-VIDEO MODE
BLACK LEVEL EXPANSION
GAMMA SELECTION
IMAGE FLIP
SCAN MODE
SCAN CONVERSION
FILM MODE
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
:RETURN MENU :EXIT MENU
SCAN CONVERSION
PROGRESSIVE / INTERLACE
+ -: SEL EXIT
:RETURN MENU :EXIT MENU
IR CONTROL
NORMAL
PRIMARY
SECONDARY
LOCK
:SEL SET :SET EXIT
ADVANCED OPTION
S-VIDEO MODE
BLACK LEVEL EXPANSION
GAMMA SELECTION
IMAGE FLIP
SCAN MODE
SCAN CONVERSION
FILM MODE
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
:RETURN MENU :EXIT MENU
SCAN MODE
OVERSCAN / UNDERSCAN
+ -: SEL EXIT
MENU :EXIT MENU :RETURN
FILM MODE
AUTO / OFF
+ -: SEL EXIT
ADVANCED OPTION
S-VIDEO MODE
BLACK LEVEL EXPANSION
GAMMA SELECTION
IMAGE FLIP
SCAN MODE
SCAN CONVERSION
FILM MODE
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
SCAN CONVERSION
MONITOR ID
IR CONTROL
TILING
SCAN MODE
*:INPUT DVD/HD,VIDEO only
FILM MODE
*:INPUT DVD/HD,VIDEO only
IMAGE FLIP
ADVANCED OPTION
MONITOR ID
IR CONTROL
TILING
HEAT STATUS
POWER ON DELAY
DATE & TIME
SCHEDULE
ADVANCED OPTION RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT MENU :EXIT MENU
TILING
:SEL
H MONITORS
V MONITORS
POSITION
FRAME COMP.
ENABLE
1
1
1
YES / NO
YES / NO
EXIT :RETURN
+ -: ADJ
ADVANCED OPTION
MONITOR ID
IR CONTROL
TILING
HEAT STATUS
POWER ON DELAY
DATE & TIME
SCHEDULE
ADVANCED OPTION RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU EXIT
MONITOR ID
IR CONTROL
TILING
HEAT STATUS
POWER ON DELAY
DATE & TIME
SCHEDULE
ADVANCED OPTION RESET
:SEL SET :NEXT :RETURN MENU :EXIT MENU
ADVANCED OPTION
EXIT
