4 - 3
TM
CHAP.
4
PRELOADED PATTERN
As the KB3100 series satisfies so many application requirements easily, it is
naturally impossible to give a definite set of key definitions to serve most of its
application. However, this keyboard is preloaded with a particular pattern on the page
LP before it is delivered. Please refer to the print-out on next page for the key
definition of each location of this preloaded pattern. The purpose of this preloaded
page is to serve the software designer so that you won’t have to connect an external
PC keyboard when you start to program the POS programmable keyboard.
To preserve this preloaded pattern into a computer file for later use, the user
should refer to the “readme” file on the attached diskette in the accessory box and
issue the following command from the subdirectory where the user keeps the
keyboard driver to store the preloaded pattern in the file “KB3100.TPL”:
rwm kb3100.tpl -r
