This turnable electronic key switch is delivered with a set of 4 pcs keys, each
marked as “PRG:, “REG”, “Z” and “GT”. The effective range of each of the 4 keys can
be illustrated by the following table and drawing.
PRG
REG
Z
GT
LP
Y
N
N
N
L0
Y
Y
Y
Y
L1
Y
Y
Y
Y
L2
Y
Y
Y
Y
L3
Y
N
Y
Y
L4
N
N
N
Y
LO
L1
L2
L3
L4
LP
MAGNETIC
STRIPE
READER
POWER
30
°
30
°
30
°
45
°
45
°
Fig. 4 - 2 Range for each key type
