34020201EN/AB - Page 27
6. Appendices
# Bit R/W NV Description
136 R/W NV Major alarm threshold (%) for circuit 01
137 R/W NV Major alarm threshold (%) for circuit 02
138 R/W NV Major alarm threshold (%) for circuit 03
139 R/W NV Major alarm threshold (%) for circuit 04
140 R/W NV Major alarm threshold (%) for circuit 05
141 R/W NV Major alarm threshold (%) for circuit 06
142 R/W NV Major alarm threshold (%) for circuit 07
143 R/W NV Major alarm threshold (%) for circuit 08
144 R/W NV Major alarm threshold (%) for circuit 09
145 R/W NV Major alarm threshold (%) for circuit 10
146 R/W NV Major alarm threshold (%) for circuit 11
147 R/W NV Major alarm threshold (%) for circuit 12
148 R/W NV Major alarm threshold (%) for circuit 13
149 R/W NV Major alarm threshold (%) for circuit 14
150 R/W NV Major alarm threshold (%) for circuit 15
151 R/W NV Major alarm threshold (%) for circuit 16
152 R/W NV Major alarm threshold (%) for circuit 17
153 R/W NV Major alarm threshold (%) for circuit 18
154 R/W NV Major alarm threshold (%) for circuit 19
155 R/W NV Major alarm threshold (%) for circuit 20
156 R/W NV Major alarm threshold (%) for circuit 21
157 R/W NV Major alarm threshold (%) for circuit 22
158 R/W NV Major alarm threshold (%) for circuit 23
159 R/W NV Major alarm threshold (%) for circuit 24
160 R/W NV Major alarm threshold (%) for circuit 25
161 R/W NV Major alarm threshold (%) for circuit 26
162 R/W NV Major alarm threshold (%) for circuit 27
163 R/W NV Major alarm threshold (%) for circuit 28
164 R/W NV Major alarm threshold (%) for circuit 29
165 R/W NV Major alarm threshold (%) for circuit 30
166 R/W NV Major alarm threshold (%) for circuit 31
167 R/W NV Major alarm threshold (%) for circuit 32
168 R/W NV Major alarm threshold (%) for circuit 33
169 R/W NV Major alarm threshold (%) for circuit 34
170 R/W NV Major alarm threshold (%) for circuit 35
171 R/W NV Major alarm threshold (%) for circuit 36
172 R/W NV Major alarm threshold (%) for circuit 37
173 R/W NV Major alarm threshold (%) for circuit 38
174 R/W NV Major alarm threshold (%) for circuit 39
175 R/W NV Major alarm threshold (%) for circuit 40
176 R/W NV Major alarm threshold (%) for circuit 41
177 R/W NV Major alarm threshold (%) for circuit 42
178 R/W NV Minor alarm delay for circuit 01
179 R/W NV Minor alarm delay for circuit 02
180 R/W NV Minor alarm delay for circuit 03
181 R/W NV Minor alarm delay for circuit 04
182 R/W NV Minor alarm delay for circuit 05
183 R/W NV Minor alarm delay for circuit 06
184 R/W NV Minor alarm delay for circuit 07
185 R/W NV Minor alarm delay for circuit 08
186 R/W NV Minor alarm delay for circuit 09
187 R/W NV Minor alarm delay for circuit 10
188 R/W NV Minor alarm delay for circuit 11
189 R/W NV Minor alarm delay for circuit 12
190 R/W NV Minor alarm delay for circuit 13
191 R/W NV Minor alarm delay for circuit 14
192 R/W NV Minor alarm delay for circuit 15
193 R/W NV Minor alarm delay for circuit 16
194 R/W NV Minor alarm delay for circuit 17
195 R/W NV Minor alarm delay for circuit 18
196 R/W NV Minor alarm delay for circuit 19
197 R/W NV Minor alarm delay for circuit 20
198 R/W NV Minor alarm delay for circuit 21
199 R/W NV Minor alarm delay for circuit 22
200 R/W NV Minor alarm delay for circuit 23
201 R/W NV Minor alarm delay for circuit 24
Minor alarm time delay for each output
circuit.
This delay is expressed in seconds (from 0
to 65535 seconds).
The factory setting is 10 seconds.
These registers define the major alarm
thresholds.
A major alarm occurs when the current in a
given output circuit is greater than the major
alarm threshold a duration exceeding the
major alarm time delay.
The units are in % (80 = 80%).
The setting range is from 0 to 100.
The factory setting is 80.
