Page 26 - 34020201EN/AB
6. Appendices
# Bit R/W NV Description
69 R/W NV Rating of breaker on circuit 18
70 R/W NV Rating of breaker on circuit 19
71 R/W NV Rating of breaker on circuit 20
72 R/W NV Rating of breaker on circuit 21
73 R/W NV Rating of breaker on circuit 22
74 R/W NV Rating of breaker on circuit 23
75 R/W NV Rating of breaker on circuit 24
76 R/W NV Rating of breaker on circuit 25
77 R/W NV Rating of breaker on circuit 26
78 R/W NV Rating of breaker on circuit 27
79 R/W NV Rating of breaker on circuit 28
80 R/W NV Rating of breaker on circuit 29
81 R/W NV Rating of breaker on circuit 30
82 R/W NV Rating of breaker on circuit 31
83 R/W NV Rating of breaker on circuit 32
84 R/W NV Rating of breaker on circuit 33
85 R/W NV Rating of breaker on circuit 34
86 R/W NV Rating of breaker on circuit 35
87 R/W NV Rating of breaker on circuit 36
88 R/W NV Rating of breaker on circuit 37
89 R/W NV Rating of breaker on circuit 38
90 R/W NV Rating of breaker on circuit 39
91 R/W NV Rating of breaker on circuit 40
92 R/W NV Rating of breaker on circuit 41
93 R/W NV Rating of breaker on circuit 42
94 R/W NV Minor alarm threshold (%) for circuit 01
95 R/W NV Minor alarm threshold (%) for circuit 02
96 R/W NV Minor alarm threshold (%) for circuit 03
97 R/W NV Minor alarm threshold (%) for circuit 04
98 R/W NV Minor alarm threshold (%) for circuit 05
99 R/W NV Minor alarm threshold (%) for circuit 06
100 R/W NV Minor alarm threshold (%) for circuit 07
101 R/W NV Minor alarm threshold (%) for circuit 08
102 R/W NV Minor alarm threshold (%) for circuit 09
103 R/W NV Minor alarm threshold (%) for circuit 10
104 R/W NV Minor alarm threshold (%) for circuit 11
105 R/W NV Minor alarm threshold (%) for circuit 12
106 R/W NV Minor alarm threshold (%) for circuit 13
107 R/W NV Minor alarm threshold (%) for circuit 14
108 R/W NV Minor alarm threshold (%) for circuit 15
109 R/W NV Minor alarm threshold (%) for circuit 16
110 R/W NV Minor alarm threshold (%) for circuit 17
111 R/W NV Minor alarm threshold (%) for circuit 18
112 R/W NV Minor alarm threshold (%) for circuit 19
113 R/W NV Minor alarm threshold (%) for circuit 20
114 R/W NV Minor alarm threshold (%) for circuit 21
115 R/W NV Minor alarm threshold (%) for circuit 22
116 R/W NV Minor alarm threshold (%) for circuit 23
117 R/W NV Minor alarm threshold (%) for circuit 24
118 R/W NV Minor alarm threshold (%) for circuit 25
119 R/W NV Minor alarm threshold (%) for circuit 26
120 R/W NV Minor alarm threshold (%) for circuit 27
121 R/W NV Minor alarm threshold (%) for circuit 28
122 R/W NV Minor alarm threshold (%) for circuit 29
123 R/W NV Minor alarm threshold (%) for circuit 30
124 R/W NV Minor alarm threshold (%) for circuit 31
125 R/W NV Minor alarm threshold (%) for circuit 32
126 R/W NV Minor alarm threshold (%) for circuit 33
127 R/W NV Minor alarm threshold (%) for circuit 34
128 R/W NV Minor alarm threshold (%) for circuit 35
129 R/W NV Minor alarm threshold (%) for circuit 36
130 R/W NV Minor alarm threshold (%) for circuit 37
131 R/W NV Minor alarm threshold (%) for circuit 38
132 R/W NV Minor alarm threshold (%) for circuit 39
133 R/W NV Minor alarm threshold (%) for circuit 40
134 R/W NV Minor alarm threshold (%) for circuit 41
135 R/W NV Minor alarm threshold (%) for circuit 42
These registers define the minor alarm
thresholds.
A minor alarm occurs when the current in a
given output circuit is greater than the minor
alarm threshold and less than the major
alarm threshold for a duration exceeding the
minor alarm time delay.
The units are in % (60 = 60%).
The setting range is from 0 to 100.
The factory setting is 60.
A minor alarm is not activated if the current
goes instantaneously from one threshold to
the other.
