DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 69
engine Operating paneL assy.
no. part no. part name QTY. remarKS
1 C2351101903 OPERATING PANEL ............................................1 ...........DCA300SSC
1 M5351100003 OPERATING PANEL ............................................1 ...........DCA300SSCU
2 0017106020 HEX HEAD BOLT .................................................8 ...........DCA300SSC
2 0017106016 HEX HEAD BOLT .................................................8 ...........DCA300SSCU
3 0207006000 HEX NUT 4
4 0602101000 BATTERY SWITCH 1
5 0021008080 MACHINE SCREW 2
5A 0030004000 HEX NUT 2
5B 0040008000 WASHER, LOCK 2
5C 0041608000 WASHER, FLAT 2
6 0601830710 ENGINE SPEED SWITCH 1
7 0601831557 EMERGENCY STOP BUTTON 1
8 0602120095 TACHOMETER 1
9 0602122093 OIL PRESSURE GAUGE 1
10 0601842450 VOLTAGE DIVIDER 1
11 0602123092 WATER TEMPERATURE GAUGE 1
12 0602121081 CHARGING AMMETER 1
13 0602125091 FUEL GAUGE 1
14 0602103090 ALARM LAMP 5
14A 0601810244 BULB, DC28V 5
15 M5483000003 SET FRAME 1
16 0017110030 HEX HEAD BOLT .................................................2 ...........DCA300SSC
16 0016910030 HEX HEAD BOLT .................................................2 ...........DCA300SSCU
17 0017110030 HEX HEAD BOLT 3
17A 0030010000 HEX NUT 3
17B 0040010000 WASHER, LOCK 3
17C 0041610000 WASHER, FLAT 6
