DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 63
cOntrOL bOx assy. (cOntinUeD)
no. part no. part name QTY. remarKS
37 M5260500204 BRACKET 1
38 0602103090 DIAGNOSTIC LAMP 2
38A 0601810244 BULB, DC28V 2
39 0601831670 DIAGNOSTIC BUTTON 1
40 0601831205 RESET BUTTON 1
41 0601830746 LOW IDLE SPEED SWITCH 1
42 0601830710 DIAGNOSTIC SWITCH 1
43 0601840009 RHEOSTAT, 2W 5k OHM 1
44 0017106016 HEX HEAD BOLT 4
45 0602201455 RELAY, HEATER 1
46 0017106016 HEX HEAD BOLT 2
47 C2224000503 CONTROL PANEL 1
48 C2224001504 CONTROL PANEL 1
49 0605011211 PIN 2
50 0601807622 FREQUENCY METER, 45~65Hz 220V 1
51 0601806979 AC AMMETER, 0~1000A 1
52 0601801040 CHANGE- OVER SWITCH, AMMETER 1
53 0601806887 AC VOLTMETER, 0~600V 1
54 0601801041 CHANGE- OVER SWITCH, VOLTMETER 1
55 0601810072 PILOT LAMP 1
55A 0601810261 BULB, 13W 1
56 0601840073 RHEOSTAT (VR), 2W 1K OHM 1
57 0601840121 KNOB 1
58 ECU9988N220V ENGINE CONTROLLER ................................. 1 ...............REPLACES P/N 0602202545
59 0601830765 SWITCH 1
60 0601810171 PANEL LIGHT, DC24V 1
61 0027104020 MACHINE SCREW 2
61A 0207004000 HEX NUT 2
62 0601830710 SWITCH, PANEL LIGHT 1
63 C9221100004 HEX HEAD BOLT 2
63A 0040008000 WASHER, LOCK 2
63B 0041208000 WASHER, FLAT 2
63C 0080200007 SNAP RING 2
64 0017108040 HEX HEAD BOLT 4
65 3871824004 STOPPER, CONTROL PANEL 1
66 0041206000 WASHER, FLAT 1
67 0605010502 SNAP PIN 1
68 C2214500004 COVER, CONTROL BOX 1
69 0017108020 HEX HEAD BOLT 8
70 C2214300004 SIDE PANEL, CONTROL BOX 1
71 0017108020 HEX HEAD BOLT 4
72 C2214400504 PANEL, CONTROL BOX 1
73 0017108020 HEX HEAD BOLT 9
74 0017110025 HEX HEAD BOLT 4
