Printer overview
These are the main components of your machine:
Front view
1 ADF (automatic
document feeder)
1
1. Automatic document feeder is used as ADF in this user’s guide.
10 tray 1
2 document width guides 11 optional tray 2
3 document input tray 12 multi-purpose tray
4 scanner lid 13 output support
5 document output tray 14 USB memory port
6 control panel 15 multi-purpose tray
extension
7 output tray 16 multi-purpose tray paper
width guides
8 front cover 17 scanner glass
9 paper level indicator 18 toner cartridge
* The figure above shows an SCX-5530FN
with all available accessories.
Rear view
1 control board cover 7 extension telephone
socket (EXT)
2 network port 8 duplex unit a
3 USB port 9 power receptacle
4 parallel port 10 power switch
5 optional tray 2 cable
connector 11 rear cover
6 telephone line socket
(LINE)
a
* The figure above shows an SCX-5530FN
with all available accessories.
