DCA-15SPX3 GENERATOR — PARTS & OPERATION MANUAL — REV. #2 (09/03/01) — PAGE 67
27 0810015204 HINGE 2
0810015504 WASHER 2
28 0017106016 HEX. HEAD BOLT 4
29 8345161302 ROOF PANEL 1
8345961304 ACOUSTIC SHEET 1
30 011008020 HEX. HEAD BOLT .............................. 16 ............. REPLACES 0017108020
31 8345172103 SIDE PANEL 1
8345972204 ACOUSTIC SHEET 1
32 8345173104 DUCT 1
33 0207006000 HEX. NUT 5
34 011208035 HEX. HEAD BOLT ................................ 6 ............. REPLACES 0017108035
35 8345170203 SIDE DOOR 1
8345970504 ACOUSTIC SHEET 1
36 8435170203 SIDE DOOR 1
8345970404 ACOUSTIC SHEET 1
37 8345171114 DUCT 1
38 0207006000 HEX. NUT 7
39 B9114000002 DOOR HANDLE 1
40 0021806016 MACHINE SCREW 4
41 8435149104 WINDOW PLATE 1
42 0027103010 MACHINE SCREW 4
0207003000 HEX. NUT 4
43 M9110100304 HINGE .................................................. 2 ............. REPLACES 0845047204
0845045004 WASHER 2
44 M911B110204 HINGE .................................................. 2 ............. REPLACES 0845047104
0845045004
WASHER 2
45 011008020 HEX. HEAD BOLT ................................ 8 ............. REPLACES 0017108020
46 0845031504 CAP 4
47 0601851613 STOPPER ............................................ 2 ............. CP30FF15A
48 0600500090 EMBLEM 1
49 0021106016 MACHINE SCREW 2
ENCLOSURE ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
DCA-15SPX3 — ENCLOSURE ASSY.
