DCA-15SPX3 GENERATOR — PARTS & OPERATION MANUAL — REV. #2 (09/03/01) — PAGE 65
DCA-15SPX3 — ENCLOSURE ASSY.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1- ORANGE
2- WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
ENCLOSURE ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
1 7675111602 BASE 1
2 8445116114 FLOOR PANEL 1
3 0017106016 HEX. HEAD BOLT 8
4 7675121202 FRONT FRAME 1
8345921204 ACOUSTIC SHEET 1
8345924004 ACOUSTIC SHEET 1
5 011008020 HEX. HEAD BOLT ................................ 7 ............. REPLACES 0017108020
6 1625165103 FILLER COVER 1
7 1625165204 CHAIN 1
8 011008020 HEX. HEAD BOLT ................................ 1 ............. REPLACES 0017108020
9 8342313003 COVER, MUFFLER 1
8345925004 ACOUSTIC SHEET 1
10 011008020 HEX. HEAD BOLT ................................ 4 ............. REPLACES 0017108020
11 8435125004 COVER, FRONT FRAME 1
8345923004 ACOUSTIC SHEET 1
12 011008020 HEX. HEAD BOLT ................................ 6 ............. REPLACES 0017108020
13 8345130203 HANGER 1
14 8435132113 HANGER 1
15 012212030 HEX. HEAD BOLT ................................ 6 ............. REPLACES 0017112030
16 7675141802 REAR FRAME 1
17 011008020 HEX. HEAD BOLT ................................ 7 ............. REPLACES 0017108020
18 8345144604 COVER, REAR FRAME 1
19 8345143203 DUCT 1
8345943004 ACOUSTIC SHEET 1
20 0207006000 HEX. NUT 4
21 011008020 HEX. HEAD BOLT ................................ 6 ............. REPLACES 0017108020
22 7675146103 DOOR, REAR FRAME 1
23 8435149004 WINDOW PLATE 1
24 0207006000 HEX. NUT 8
25 0605010230 DOOR HANDLE 1
26 0021805012 MACHINE SCREW 4
