PAGE 32 — DCA-15SPX3 GENERATOR— PARTS & OPERATION MANUAL — REV. #2 (09/03/01)
General Inspection Prior to Operation
The DCA-15SPX3 generator has been thoroughly inspected
and accepted prior to shipment from the factory. However,
be sure to check for damaged parts or components, or loose
nuts and bolts, which could have occurred in transit.
Extension Cable
When electric power is to be provided to various tools or
loads at some distance from the generator, extension
cords are normally used. Cables should be sized to allow
for distance in length and amperage so that the voltage
drop between the generator and point of use (load) is
held to a minimum. Use Table 6 (cable selection guide)
as a guide for selecting proper cable size.
Circuit Breaker
To protect the generator from an overload,
a 3-pole, 65 amp,
main
main
main
main
main circuit breaker is provided to protect the UNV output
from overload. In addition a 2-pole, 20 amp GFCI
GFCI
GFCI
GFCI
GFCI circuit
breaker is provided to protect the GFCI receptacle from
overload. Make sure to switch both circuit breakers to the
"OFF" position prior to starting the engine.
