54
Format (picture shape) availability based on Input/Signal
NOTE: You can find aspect ratios on the back of most DVD covers. Also, Anamorphic DVDs are usually
marked “Anamorphic” or “Enhanced for 16:9 TVs.”
Available On-Screen Format Sizes
Zoom
Enlarges the picture, cropping some of the image
at each side, top and bottom. The Zoom format
is useful to remove or reduce the black top and
bottom bars on Anamorphic DVDs with 2.35:1
aspect
ratio.
Note: Zoom is not available with 1080i/720p
signal.
Stretch
Default format for ANT and Inputs 1-2. The
Stretched format stretches narrow 4:3 images
across the screen, however, there is less stretch in
the center than the sides.
Note: Stretch is not available with 1080i/720p
signal.
Narrow
Displays narrow 4:3 images in their original shape
and adds stationary gray side bars to fill the screen.
Note: Narrow is not available with 1080i/720p
signal.
Wide (PC)
This format is only available with PC signal.
Standard
Default format for DTV and Component Input
displays a full-screen format. The Standard format
displays Anamorphic DVDs that have the 1.78:1 or
1.85:1 aspect ratios. However, Anamorphic DVDs
that have the 2.35:1 aspect ratio still display black
bars at the top and bottom of the screen, while
narrow (4:3) images are stretched evenly from side
to side.
Expand (480i/480p)
Enlarges the picture, cropping some of the image
at the top and bottom. The Expand format is
useful to reduce the letterbox top and bottom bars
of non-Anamorphic DVDs or to correct narrow 4:
3 images that have been stretched in the Standard
format.
Note: Expand is not available with 1080i/720p
signal.
HD Expand (1080i/720p)
Enlarges the picture to fit the screen vertically,
cropping some of the image on both sides. This
format is useful to remove or reduce black side bars
on HD broadcasts of 4:3 images with black bars
(See page 55).
Note: HD Expand is only available with 1080i/
720p signal.
INPUTS Standard Expand
i/p
Expand HD
i/p
Zoom Stretch Narrow Wide
ANT YES YES NO YES YES YES NO
Input- YES YES NO YES YES YES NO
Input- YES YES NO YES YES YES NO
Component- or  (i/p) YES YES NO YES YES YES NO
Component- or  (i/p) YES NO YES NO NO NO NO
DVI (i/p) YES YES NO YES YES YES NO
DVI (i/p) YES NO YES NO NO NO NO
PC NO NO NO NO NO YES YES
