48
ENGLISH
MULTI ROOM
SYSTEM
(SR5002 only)
The Multi Room system is a function which allows
you to listen to the same or a different source in a
room other than the room in which the SR5002 is
located.
The operations possible with the multi room function
are explained briefl y below.
For details, refer to the instruction manual supplied
with the multi room remote controller and SR5002.
When the outputs of the MULTI OUT terminals are
wired and connected to amplifi ers installed in other
rooms or M (MULTI) SPEAKER B terminals are
wired and connected to L&R speakers in other room,
different sources can be played in rooms other than
the main room in which the SR5002 and the playback
devices are installed.
SR5002 has some feature to MULTI ROOM SYSTEM
as source selector, sleep timer, Multi Room Speaker
output and remote control.
MULTI ROOM PLAYBACK USING THE MULTI
ROOM OUT TERMINALS
The SR5002 is equipped with audio pre-out terminals
for which the volume is adjustable as the MULTI
output terminals.
A separately sold stereo power amplifier can be
connected to enjoy multi room playback.
MULTI SPEAKER
DIGITAL R L VIDEO S-VIDEO AUX 1 INPUT AUDIO
SETUP SIMPLE MULTI PURE
T-MODE
SURROUND MEMORY DISPLAY ATT MUTE
STANDBY
INPUT SELECTOR VOLUME
UP DOWN
AV SURROUND RECEIVER SR5002
DIRECT
AUTO HT-EQ EXIT MENU
MODE
BAND
CLEAR
ENTER
PHONES POWER ON/STANDBY SETUP MIC
2. 3. 1. 4.
CAT
CAT
-
T.DISP F.DIRECT PTY
TUNING PRESET - + +
+10
REMOTE CONTROLLER
0 0
BASS TREBLE
MULTI/
MENU
SPKR A/B
ENTER
EXIT
INFO
CH/
T.TONE
/SET UP
M-SPKR
MUTE
MD CDR CD
AMP AUX2
TUNER
REC
AUDIO ANGLE SUB TITLE DISC+
CH-SEL V-OFF ATT.
AUX1
MEMO CL
DVD DVD VCR VCR DSS DSS TV TV
VOLUME VOLUME
TAPE
1. 4.
2.
3.
1. 4.
1. Press the MULTI button on the unit or remote
controller (after pressing the AMP button
on the remote controller). The unit enters
MULTI ROOM mode, and the display indicates
“SELECT SOURCE.” The “MULTI” indicator will
fl ash for about 10 seconds.
2. Select the input source using the INPUT
SELECTOR knob or function button on the
remote controller.
Then, the display indicates “MULTI VOLUME”
“MULTI VOL. xx” for approx. 5 seconds.
3. During this time, you can set the volume level in
the multi room as desired.
This will only set the volume in the second room.
4. To cancel this function, press the MULTI button
on the unit or remote controller (after pressing
the AMP button on the remote controller).
“MULTI” indicator on the front panel will be
turned off.
MULTI ROOM PLAYBACK USING THE MULTI
SPEAKER TERMINALS
The SR5002 allows you to connect another set
of speakers and place them in a different room or
separated area for listening to music.
MULTI SPEAKER
DIGITAL R L VIDEO S-VIDEO AUX 1 INPUT AUDIO
SETUP SIMPLE MULTI PURE
T-MODE
SURROUND MEMORY DISPLAY ATT MUTE
STANDBY
INPUT SELECTOR VOLUME
UP DOWN
AV SURROUND RECEIVER SR5002
DIRECT
AUTO HT-EQ EXIT MENU
MODE
BAND
CLEAR
ENTER
PHONES POWER ON/STANDBY SETUP MIC
2. 3. 1. 4.
CAT
CAT
-
T.DISP F.DIRECT PTY
TUNING PRESET - + +
+10
REMOTE CONTROLLER
0 0
BASS TREBLE
MULTI/
MENU
SPKR A/B
ENTER
EXIT
INFO
CH/
T.TONE
/SET UP
M-SPKR
MUTE
MD CDR CD
AMP AUX2
TUNER
REC
AUDIO ANGLE SUB TITLE DISC+
CH-SEL V-OFF ATT.
AUX1
MEMO CL
DVD DVD VCR VCR DSS DSS TV TV
VOLUME VOLUME
TAPE
1. 4.
2.
3.
1. 4.
1. Press the MULTI SPEAKER (M-SPKR) button.
The unit enters multi room speaker mode and
the display indicates “SELCT SOURCE” and
fl ashes the “MULTI” indicators for approx. 10
seconds.
2. Select the input source using the INPUT
SELECTOR knob or function button on the
remote controller.
Then, the display indicates “MSPKR VOLUME”
“MSPKR VOL.–xx” for approx. 5 seconds.
3. During this time, you can set the volume level in
the multi room as desired.
This will only set the volume in the multi room.
4. To cancel this function, press the MULTI button
on the unit or remote controller (after pressing
the AMP button on the remote controller).
“MULTI” indicator on the front panel will be
turned off.
Notes for MULTI ROOM SPEAKER
• MULTI ROOM SPEAKER On/ Off is available in
main room only.
• MULTI ROOM SPEAKER output terminals can
be used when the SURROUND BACK SPEAKER
is set NONE in SPEAKER SETUP menu. (See
SPEAKER SETUP, page 27)
• “The Surr. Back Speakers are in use” is displayed
by pressing the MULTI SPEAKER (M-SPKR)
button when the SURROUND BACK SPEAKER is
set except NONE in SPEAKER SETUP menu. (See
SPEAKER SETUP, page 27)
