Marantz SR4002/SR5002 - Manual (Page 13)

10
ENGLISH
9/NIGHT button
Pressing this button prevents the Dolby Digital
signal from playback at a loud voice. This function
reduces the voice by 1/3 to 1/4 at maximum. Thus, it
eliminates the occurrence of an abruptly loud voice
at night. However, the function is valid only in the
case when the Dolby Digital signal is entered into
OPTICAL or COAXIAL and data to compress the
voice exists in the signal to be played back.
When this button is pressed, the “NIGHT” indicator
is illuminated.
0/7.1CH IN button
This button is used to select the output of an external
multi channel decoder.
(+10) A/D button
This button is used to switch between the analog and
digital inputs.
m CL (Clear) button
This button is used to erase the memory or program
of a source.
, SPKR A/B button (SR5002 only)
This button is used to select the speaker system.
The speaker system is switched in the following
sequence.
A → B → A+B → off
. CH/CAT 3 (UP) / 4 (DOWN) buttons
These buttons are used to change channels.
⁄0 MULTI/CAT button (SR5002 only)
(When AMP mode is selected)
This button is used to turn on and off multi room.
⁄1 INFO button
(When AMP mode is selected)
When this button is pressed, the current setting are
displayed on the TV monitor.
⁄2 T.TONE/SET UP button
(When AMP mode is selected)
This button is used to enter the test tone menu. (2-4
speakers level)
⁄3 CONTROL buttons
These buttons are used when operating PLAY, STOP,
PAUSE and other commands of a source.
(When TUNER mode is selected)
T.DISP button
This button is used to select the display mode in
RDS.
PTY button
This button is used to display the programme type
information of the current station.
F.DIRECT button
This button is used to select the "Frequency direct
input".
PRESET +/- buttons
This button is used to select a preset station up and
down.
TUNING +/- buttons
This button is used to tune a frequency station up
and down.
⁄4 ANGLE/V-OFF buton
(When AMP mode is selected)
This button is used to turn off the video signal.
⁄5 DISC+/CH. SEL button
(When AMP mode is selected)
This button is used to call up CH LEVEL ADJUST
and adjust speaker levels or 7.1 ch input level.
⁄6 BASS +/- buttons
These buttons are used to adjust the tone control
of low frequency sound for left, right and subwoofer
speaker.
⁄7 SEND indicator
Indicates when the remote controller is transmitting
a signal.
⁄8 / POWER ON and OFF buttons
(When AMP mode is selected)
These buttons are used to turn the unit on or off.
⁄9 SURROUND button
This button is used to selects the surround mode.
REMOTE CONTROLLER
The provided remote controller is a universal
remote controller. The POWER button, numeric
buttons and control buttons are used in common
across different input source components.
The input source controlled with the remote controller
changes when one of the input selector buttons is
pressed.
z LEARN indicator
Indicates when the remote controller is in the LEARN
mode.
x SET button
This button is used to enter learn mode and preset
mode.
c / SOURCE ON/OFF button
This button is used to turn a specifi c source (such as
a DVD player) on or off independently from the rest
of the system.
v SLEEP button
This button is used for setting the sleep timer.
b DISPLAY button
This button is used to selects the display mode for the
front display of the unit.
n Numeric buttons
These buttons are used to switch between 0 to +10
of the source components.
If the source is set to the amplifi er, these buttons are
used to perform operations.
(When AMP mode is selected)
1/AUTO button
This button is used to select auto surround.
2/Dolby button
This button is used to select DOLBY mode.
3/dts button
This button is used to select dts mode.
4/CSII button
This button is used to select CSII mode.
5/EX/ES button
This button is used to select EX/ES mode.
6/VIRTUAL button
This button is used to select VIRTUAL mode.
7/M-CH ST button
This button is used to select Multi Channel Stereo.
8/STEREO button
This button is used to select STEREO mode.
TAPE
CAT
P.SCAN
CAT
T.MODE
-
T.DISP F.DIRECT PTY
TUNING PRESET - + +
1 2 3
4 5 6
7 8 9
0 +10
REMOTE CONTROLLER
HT-EQ
MULTI/
SEND
MENU
SPKR A/B
ENTER
EXIT
INFO
CH/
INPUT
T.TONE
/SET UP
M-SPKR
MUTE
MD CDR CD
DVD
AMP AUX2
VCR
TUNER
DSS TV
EX/ES VIRTUAL CS
VOLUME
BASS TREBLE
dts
P.DIRECT
l/
OFF ON SET
7.1CH IN
STEREO NIGHT M-CH ST
AUTO
SURROUND SLEEP DISPLAY
REC
AUDIO ANGLE SUB TITLE DISC+
CH-SEL V-OFF ATT.
AUX1
A/D
LEARN
LIP SYNC/
MEMO
BAND
CL
SOURCE
z
m
.
⁄1
⁄2
⁄3
⁄6
⁄5
c
v
x
‹0
n
b
,
⁄0
⁄4
¤9
¤8
‹4
¤6
¤4
¤3
‹5
¤2
¤0
¤1
⁄7
⁄9
‹2
‹3
‹1
⁄8
¤5
¤7
