SECTION 8 − USING THE OPTIONAL DATA CARD

8-1. Data Card Terms

SA-158 435

>W r i t e

R e a d
D e l e t e
D o n e

READ Programs From Card

WRITE Programs To Card

CARD SCREEN TERMS

PULSE MIG TERMS

PPS

(Pulses Per

Second)

Apk (Peak

Amperage)

PWms

(Pulse Width In

Milliseconds)

Abk

(Background

Amperage)

Time

Amperage

8-2. Installing Data Card

ST-156 266-B

1

Label

Apply label to data card. Write pro-

gram information on label.
2

Data Card

3

Card Slot

For Blank Data Card:
Insert card into slot. To format card,

turn On power. Select Card from

menu. Data card formats when unit

enters Card mode.

1

2

3
