Chapter 3: Software Support

3.2.5 Link State

Displays the current connection status of the Wireless USB adaptor to the
AP or to other Wi-Fi devices. An icons represents the Link State for easy
identification. Refer to the table below for icon indications.

Table of Icon Indications

3.2.4 About Wireless Settings

Click the About icon to view the
software version, driver version, and
copyright information.

Excellent link quality (Infrastructure)

Good link quality (Infrastructure)

Fair link quality (Infrastructure)

Poor link quality (Infrastructure)

Not linked (Infrastructure)

Linked (Ad-hoc)

Not linked (Ad-hoc)
