Network Stand Alone DVR

Network (JPEG2000+H.264)

CHAP. 5 Set Up

3) PANTILT SETUP

It is to set parameters for PTZ camera connected to DVR unit. DVR unit already includes all
protocols of well-known PTZ cameras like PELCO D type PTZ camera, and user just select MODEL
and set other parameters to control this PTZ cameras, using operation buttons on the front panel of
DVR.

PANTILT SETUP

COMMAND SETTING

PTZ camera set

SPEED SETTING

PTZ speed set

SELECT : ▲▼, & [ENTER]

COMMAND SETTING

CHANNEL

MODEL
PTZ ID
BAUDRATE
CMD DELAY

COMMAND

LENGTH
CODE

01
PELCO-D
000
2400 BPS
1 MSEC

PAN/TILT STOP
07
FF 00 00 00
00 00 00 00

SELECT : ▲▼, CHANGE VALUE : + -

(1) CHANNEL : Select channel
(2) MODEL : Select camera model (protocol type) per each channel
(3) PTZ ID : Select ID
(4) BAUDRATE : Select data transmission speed
(5) CMD DELAY : Select command delay time

4) SPOT MONITOR SETUP

(1) SWITCHING INTERVAL

Channel switching time (01 sec. ~ 99 sec.)

(2) ALARM POP-UP

When ALARM is detected, the image of channel
connected with Alarm sensor pops up.
Set ALARM detection pop-up (ON/OFF)

(3) MOTION POP-UP

Set MOTION detection pop-up (ON/OFF)

※

EVENT POP-UP DURATION

Set EVENT POP-UP DURATION

SPOT MONITOR SETUP

SWITCH INTERVAL
03 SEC
ALARM POP UP
ON
MOTION POP UP
ON
EVENT POP UP DURATION 01
SEC

SELECT: ▲▼, CHANGE VALUE : + -

2) RS-232C SETUP

User can control the DVR via RS-232C port.
Connect DVR to PC via RS-232C port and control
DVR using keyboard of PC.
This function is mainly for programmer who
wants to control DVR as part of many devices
connected to PC system, as in SI project.

RS-232C SETUP

SPEED

LENGTH

STOP BIT

PARITY

115200

NONE

SELECT : ▲▼, CHANGE VALUE : + -
