Table 7. Five-pin DIN Female MIDI Out

Use

Name

Pin

1

Shield

GND

2

3

Reference current

+5V

4

Send data

Data

5

Table 8. XLR Female SMPTE In

Use

Name

Pin

Shield

GND

1

+Balanced analog input

+data

2

-Balanced analog input

-data

3

Table 9. XLR Male SMPTE Out

Use

Name

Pin

Shield

GND

1

+Balanced analog output

+data

2

-Balanced analog output

-data

3

41

Component Specifications
