Motorola RG2200 User Manual
Page 54
54
Single PC connected to the Internet through the RG2200
The RG2200 Ethernet output can connect to multiple PCs through the use of a hub. Whether all PCs connected in this
manner can be provided with Internet access service depends on your NSP.
AC-3
AUDIO-R
AUDIO-L
S-VIDEO
TV OUT
NETWORK IN/
TV OUT
NETWORK IN
IR
BLASTER
110-230 VAC
50-60 Hz
13A MAX
VIDEO
ETHERNET
PC
CAT 5 Ethernet
cable
RJ-45
RJ-45
