23
At a glance
Instrument cluster
Item Page
1 Coolant temperature gauge 132
2 Fuel gauge with:
Fuel reserve warning lamp 308
3 L Left turn signal
indicator lamp
47
K Right turn signal
indicator lamp
4 Speedometer with:
v ESP warning lamp 308
l Distance warning
lamp
Vehicles without Distronic*:
Warning lamp without func-
tion. It illuminates when the
ignition is on. It should go
out when the engine is run-
ning.
307
5 Tachometer 133
6 Right display with:
< Seat belt telltale 308
Item Page
A High beam headlamp
indicator
48
- Antilock Brake Sys-
tem (ABS) warning
lamp
304
7 Reset button 131
8 Display with:
ț Program mode 170
ț Gear range indicator 166
ț Digital clock (see
COMAND operating in-
structions)
9 Multifunction display
with:
ț Trip odometer 132
ț Main odometer 132
Stored speed for:
ț Cruise control 203
ț Distronic* 206
Item Page
a Outside temperature indica-
tor
133
b Left display with:
1 Supplemental
restraint system
indicator lamp
310
; Brake warning lamp,
USA only
305
3 Brake warning lamp,
Canada only
? Engine malfunction
indicator lamp, USA
only
306
± Engine malfunction
indicator lamp,
Canada only
H Tire pressure warning
lamp
287,
309
c Knob for instrument cluster
illumination
131
