99-8225G KIT ASSEMBLY
2
REAR VIEW - A/C VENT PANEL
A
B
C
D
Secure the Radio Housing into the
factory a/c vent panel using the
factory hardware. (Figure A) 1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure B) 3
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation. 2
Slide the aftermarket head unit into
the cage and secure. (Figure C) 4
* Note: Refer also to the instructions included with the aftermarket radio.
DIN HEAD UNIT PROVISION WITH POCKET
Reassemble remaining radio and
dash assemblies in reverse order of
disassembly.
5
6
Snap the factory vent panel/Radio
Housing over dash cavity. (Figure D)
