Metra Electronics 99-7500 User Manual

Installation instructions

background image

99-7500

DW-7501

INSTALLATION
INSTRUCTIONS

TOOLS REQUIRED

Cutting tool

Phillips screwdriver

Socket wrench

KIT COMPONENTS

rev. 300801

Radio
Housing #1

Radio
Housing #2

Trimplate

Bracket Set #1

(6) 3/8" Hex-head Screws

(6) ¾" Hex-head Screws

(4) ½" Hex-head
Screws

(8) 3/8" Phillips
Screws

Filler Bar

Equalizer
Dummy
Plate

APPLICATIONS

CAR

PAGE

MAZDA
323 1986-89*...............................................................................1
323 1990-94*...............................................................................1
626 (models w/factory receiver/tape deck/eq/pocket) 1986-92....2
626 (models w/factory receiver/pocket) 1986-92* ...................... 2
929 1988-91.................................................................................3
B-Series Pickup 1986-93................................................................3
Miata 1990-99.............................................................................. 4
MPV 1989-95*.............................................................................. 4
MX6 (models w/factory receiver/tape deck/eq/pocket) 1986-92...2
MX6 (models w/factory receiver/pocket) 1986-92*....................... 2
Protege 1990-94*......................................................................... 1
RX-7 1986-91............................................................................... 5

* For aftermarket DIN head unit installations, order Metra's 99-7501
For models with pockets 3¾" or taller, order Metra's 99-7501

7

INST 7500

6

B-SERIES PICKUP: Re-connect the battery terminal and test the unit for proper operation.
Mount Bracket Set #1 to the Housing with (4) ½" Hex-head Screws supplied. Mount the
head unit/kit assembly to the back of the dash trim bezel with (4) screws removed in step #1
and re-attach the bezel. (see Fig. A)

323 1986-89, 626 / MX6 (models using Radio Housing #2): Re-connect the battery terminal
and test the unit for proper operation. Mount the head unit/kit assembly to the back of the dash
trim bezel with (4) 3/8" Phillips Screws supplied and re-attach the bezel. (see Fig. B)

626 / MX6 (models using Radio Housing #1: Re-connect the battery terminal and test the
unit for proper operation. Mount the head unit/kit assembly to the back of the dash trim bezel
with (8) 3/8" Phillips Screws supplied and re-attach the bezel. (see Fig. C)

323 1990-94, MPV, PROTEGE: Re-connect the battery terminal and test the unit for proper
operation. Mount the head unit/kit assembly to the sub-dash with (4) ¾" Hex-head Screws
supplied. (see Fig. D)

929, MIATA, RX-7: Re-connect the battery terminal and test the unit for proper operation.
Mount the head unit/kit assembly to the back of the dash trim bezel with (6) 3/8" Hex-head
Screws
supplied and re-attach the bezel. (see Fig. E)

Fig. B

Fig. D

Fig. E

Fig. C

Fig. A

1-800-221-0932 www.metraonline.com
