Chapter 5 - RouteFinder Manager
Statistics Tab
The Statistics tab indicates, by port, how many bytes of data have come in and out through the
RouteFinder..
1. From the RouteFinder Monitor dialog box, click the Statistics tab.
2. The Statistics tab dialog box displays.
3. You may view the following information:
IP Address
The IP address of the network device.
Name
The Name as entered in the IP/Address name option of the Main RouteFinder Monitor dialog box.
Tx Bytes
Displays the number of bytes transmitted from the computer with this IP address.
Rx Bytes
Displays the number of bytes received from the computer with this IP address.
Total Bytes
Displays the total number of bytes received and transmitted from the computer with this IP
address.
4. Click Reset to set the IP statistics to zero.
5. To exit RouteFinder Monitor, close the window.
