To manage computer’s address manually ,perform the following functions:
1. In the Connect via menu select the Ethernet interface installed in
your computer.
2. In the Configure menu select Manually. (See Figure 3.4-2)
a). In the IP Address field, enter “192.168.1.x” where x is any vari-
able of your choice ranging from 2 - 252.
Figure 3.4-2
NOTE: No two computers on LAN is allowed to adopt the same IP address or
an IP address confict will occur.
b). In the Subnet Mask field enter “255.255.255.0”.
c). In the Router Address field enter “192.168.1.1”, the XRouter
Pro’s default address.
d). In the Name Server Address field enter the DNS information
provided by your ISP. In the Search Domains field enter the
domain information provided by your ISP.
e). Close the TCP/IP window and save the changes.
12
Chapter 3 - EASY INSTALLATION
