8 54D5031
E
H
D
A
G F
L
M
O J
3½"
⅝"
⅝"
½"
½"
I
B
8¼"
I
N
C
K
PRE-INSTALLATION INFORMATION
DESCRIPTION
Key
Letter HBDV300 HBDV400
Overall Front Width A 33 1 /
16
" 37 1 /
16
"
Inside Width B 29 7 /
8
" 32"
Glass Width C 27" 29"
CTR Pipe Rear L/R D 16 1 /
2
" 18 1 /
2
"
Rear Width E 28" 29"
Glass Height F 18" 20 3 /
8
"
Total Height G 33 7 /
8
" 40 5 /
8
"
Depth H 15" 18 1 /
4
"
Figure 3 - Fireplace Dimensions
DESCRIPTION
Key
Letter HBDV300 HBDV400
Height to Standoffs I 37" 40 5 /
8
"
CTR Pipe Height Rear J 29 5 /
8
" 33 1 /
8
"
Top Face K 2 1 /
8
" 1 1 /
4
"
Side Face L 1 1 /
2
" 2 1 /
2
"
Bottom Face M 15 /
16
" 15 /
16
"
Non-combustible N 5 1 /
4
" 6 1 /
8
"
Chassis Height O 33 3 /
4
" 37 1 /
2
"
FIREPLACE DIMENSIONS
