SLM-5650 Satellite Modem
Revision 2
Configuration
MN/SLM5650.IOM
3–7
Modulation
Type
Overhead
R-S Code
Word
R-S Depth
Data Rate
(kbps)
Symbol Rate (ksps)
Min
Max
Min
Max
OQPSK 1/2
IESS-309
208,192
4, 8, 16
64
8448
74.311
9809.067
OQPSK 3/4
None
Off
N/A
64
20000
42.666
30000
OQPSK 3/4
None
126,112
4, 8, 16
64
40000
48
30000
OQPSK 3/4
None
219,201
4, 8, 16
64
41301.369
46.487
29999.999
OQPSK 3/4
None
194,178
4, 8, 16
64
41288.65
46.502
30000
OQPSK 3/4
None
225,205
4, 8, 16
64
41000
46.829
30000
OQPSK 3/4
None
208,192
4, 8, 16
64
41339.713
46.444
30000
OQPSK 3/4
IESS-309
Off
N/A
64
8448
45.511
6007.467
OQPSK 3/4
IESS-309
126,112
4, 8, 16
64
8448
51.2
6758.4
OQPSK 3/4
IESS-309
219,201
4, 8, 16
64
8448
49.587
6545.449
OQPSK 3/4
IESS-309
194,178
4, 8, 16
64
8448
49.602
6547.464
OQPSK 3/4
IESS-309
225,205
4, 8, 16
64
8448
49.951
6593.561
OQPSK 3/4
IESS-309
208,192
4, 8, 16
64
8448
49.541
6539.378
OQPSK 7/8
None
Off
N/A
64
20000
36.571
29622.857
OQPSK 7/8
None
126,112
4, 8, 16
64
46666.666
41.143
30000
OQPSK 7/8
None
219,201
4, 8, 16
64
48184.931
39.846
29999.999
OQPSK 7/8
None
194,178
4, 8, 16
64
48170.103
38.859
30000
OQPSK 7/8
None
225,205
4, 8, 16
64
47833.333
40.139
29999.999
OQPSK 7/8
None
208,192
4, 8, 16
64
48229.665
39.81
29999.999
OQPSK 7/8
IESS-309
Off
N/A
64
8448
39.01
4827.428
OQPSK 7/8
IESS-309
126,112
4, 8, 16
64
8448
43.886
5792.914
OQPSK 7/8
IESS-309
219,201
4, 8, 16
64
8448
42.503
5610.385
OQPSK 7/8
IESS-309
194,178
4, 8, 16
64
8448
42.516
5612.112
OQPSK 7/8
IESS-309
225,205
4, 8, 16
64
8448
42.818
5561.624
OQPSK 7/8
IESS-309
208,192
4, 8, 16
64
8448
42.463
5604.181
