SLM-5650 Satellite Modem Revision 1
Remote Control MN/SLM5650.IOM
B–25
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Equipment ID N/A 17 bytes Query only.
Unit returns information concerning the equipment identification,
and the option field, in the form aaaabcdefghijklxx;
where:
aaaa = defines the modem model number (5650 in this case)
b = FEC Card #1: 0 = None, 1 = TPC
c = FEC Card #2: 0 = None, 1 = TPC
d = Option Card: 0 = None, 1 = G.703
e = Data Rate Option: 0 = Base (10,000 kbps), 1 = up to 20 kbps,
2 = up to 51840 kbps, 3 = up to 155,000 kbps,
4 = up to 200,000 kbps
f = Higher-order modulation: 0 = None, 1 = 8PSK, 2 = 8PSK and
16QAM, 3 = 8PSK, 16QAM, and 64QAM
g = Reed-Solomon Codec Option: 0 = None, 1 = Installed
h = Asymmetrical Loop Timing Option: 0 = None, 1 = Installed
i = AUPC Option: 0 = None, 1 = Installed
j = IBS Overhead Option: 0 = None, 1 = Installed
k = IDR Overhead Option: 0 = None, 1 = Installed
l = Mil-165A Overhead Option: 0 = None, 1 = Installed
x = spare
Example: EID=56500000000000000 indicates SLM-5650 with no
options installed
N/A EID? EID=aaaabcdefghijklxx
(see description of
arguments)
