EDS-518A Series User’s Manual Featured Functions
3-33
CoS Mapping
Setting Description Factory
Low/Normal/
Medium/High Set the mapping table of different CoS values to 4
different egress queues. 0: Low
1: Low
2: Normal
3: Normal
4: Medium
5: Medium
6: High
7: High
TOS/DiffServ Mapping
Setting Description Factory Default
Low/Normal/
Medium/High Set the mapping table of different TOS values to 4
different egress queues. 1 to 16: Low
17 to 32: Normal
33 to 48: Medium
49 to 64: High
