1
FORD TAURUS 2004- 2007
99-5719 DASH DISASSEMBLY
Disconnect the negative
battery terminal to prevent an
accidental short circuit.
Using Metra’s 86-5618, pull
the factory radio/climate
control panel from the dash.
(Fig. A)
Disconnect the audio system
connectors, blower motor
switch connector, vacuum
hose harness, a/c damper
door switch connector, and
potentiometer connector.
Remove the panel.
Remove (2) torx-head screws
securing the mounting clips to
the sides of the factory
radio/climate control panel
and remove the clips. (Fig. B)
Mount the clips to the
Integrated Mounting Kit with
the same torx-head screws.
1
2
3
A
B
4
5
NOTES
99-5719
