19 117846
OWNER’S MANUAL
* Available at any hardware store.
ILLUSTRATED
PARTS LIST
For Model MGH8500AIE Fuel
Tank and Roll Cage
This list contains replaceable parts used in
your generator. When ordering parts, follow
the instructions listed under Replacement
Parts
on page 25 of this manual.
KEY
NO. PART
NUMBER
DESCRIPTION QTY.
1 25954002 Gas Cap/Fuel Gage 1
2 114720-01 Gas Tank (with 90° fitting) 1
3 114787-01 Screw, 1/4"-28 x 3/4" 4
4 WP-4C Washer, 1/4" 4
5 19508001 Gas Line Clamp 2
6 25985008 Fuel Line 1
7 114714-03 Heat Shield 1
8 115398-01 Roll Cage 1
9 M10908-27 Screw #10-32 x 1/2" 8
10 116169-01 Spacer 1
11 * Bolt, 5/16"-18 x 1/2" 2
12 WLE-5 Lock Washer, 5/16" 2
13 103289-01 Shock Mount 1
14 NEC-5C Lock Nut, 5/16"-18 4
15 WP-5C Flat Washer, 5/16" 3
16 103289-02 Shock Mounts 2
17 114721-04 Control Panel Assembly 1
PARTS AVAILABLE - NOT SHOWN
100003-07 Operation Decal 1
099873-07 Battery Cable (Positive, Red) 1
099873-02 Battery Cable (Negative, Black) 1
* 5/16"-18 x 1/2" Grounding
Bolt
1
* 5/16" Flat Washer 1
* 5/16" SEMS Nut 1
