RASFinder User Guide
MTASR3-200 54
Appendix A - Cabling Diagrams
Command Port Cable
1 2 3 4 5 6 7 8
COMMAND
PIN NO.
1
2
3
4
5
6
7
8
20
22
25
1
2
3
4
5
6
7
8
To
DTE
Device
(Terminal
Device;
e.g., ASCII
Terminal)
TRANSMIT DATA (BA)
RECEIVE DATA (BB)
SIGNAL GROUND (AB)
PIN NO.
To COMMAND PORT
Connector
LAN Cables
10BASE-T
1 2 3 4 5 6 7 8
10BASE-2
ETHERNET
Pin Circuit Signal Name Pin Description
1 TD+ Data Transmit Positive 1 Center
2 TD- Data Transmit Negative 2 Shield
3 RD+ Data Receive Positive
4 RD- Data Receive Negative
WAN Cables
LINK3 LINK1 LINK2
1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6
Pin Circuit
3 Tip
4 Ring
