none of the strands from the black and red wires
are touching each other. This can create a short
circuit that can damage your electronics. Mount
the baffle to the frame using the 6 screws
provided. Do not over tighten the mounting
screws.
Step 12. After the speaker is mounted,
adjustments to the swivel tweeter (small speaker)
can be made by either directing the sound
visually or by using a musical source to
determine the best sound coverage for the
listening area. To position the tweeter, press at
the outside edge of the tweeter housing (DO
NOT PRESS ON THE CONE DIRECTLY).
Note the crease in the asymmetrical tweeter
provides the highest directional response in this
direction. See figure 11 on page 14.
If you require to disperse the sound in a 180-
degree pattern you must position the line in the
tweeter in a horizontal position. See figure 12 on
page 15.
The combination of switch settings allow you to
boost and cut bass and treble +/-3dB. Adjust the
speaker level to accommodate for room
acoustics. See figure 13 on page 15.
Step 13. Divide each adhesive bead strip in half.
(Adhesive bead strips are in the clear self-closing
bag). Place strips on the edge of the grille as
shown in figure 14 on page 15. Reinstall the grille
on the speaker.
Step 14. Adhere the WG Series logo to the grille
with the pressure sensitive tape.
