you do not cut the hole larger than the outline.
Step 7. Be sure to clear any insulation material
from the speaker back.
Step 8. After you have determined the speaker
locations secure a 16 gauge 2 conductor cable to
the stud using an insulated staple. Leave at least
18 inches of additional cable for connection
during final speaker installation. Run the other
end of the speaker cable to the audio source.
Step 9. Prepare the speaker wiring by stripping
off approximately 3 inches of the outer jacket
(care should be taken so the insulation on the
wires inside the jacket are not damaged) also
strip approximately 3/8 inch off the ends of the
two inside conductors. Twist the ends of the
stranded cable so the wires are tight.
Step 10. Follow the instructions included with the
volume control and amplifier.
Step 11. You are now ready to install the frame.
Remove the paint mask. Be careful not to touch
the speaker cones and tweeters when
removing the paint mask in order to prevent
any damage. Remove the baffle from the frame
and fasten the frame to the drywall. Index the
mounting tabs to make sure that all tabs will clear
the opening. Insert the frame in the wall and
tighten the tabs with the screws on the front of
the baffle. Attach the speaker cable to the
speaker by pressing down on the red (+) or black
(-) gold-plated push terminals and inserting the
red wire in the red terminal and the black wire in
the black terminal. See figure 10. Make sure that
