pattern you must position the line in the tweeter
in a horizontal position. See figure 5 on page 10.
The combination of switch settings allow you to
boost and cut bass and treble +/-3dB. Adjust the
speaker level to accommodate for room
acoustics. See figure 6 on page 10.
Step 13. Divide each adhesive bead strip in half.
(Adhesive bead strips are in the clear self-closing
bag). Place strips on the edge of the grille as
shown in figure 7 on page 10. Reinstall the grille
on the speaker.
Step 14. Adhere the WG Series logo to the grille
with the pressure sensitive tape.
Repeat steps for the second speaker.
In-wall Speakers
For existing construction, the use of rough-in
rings can not occur. The following steps outline
how to locate a section between two wall studs,
mark the outer boundaries of the hole, drill a
small hole in the center to verify the location and
then cut the main hole.
Step 1. Determine the location of the wall studs
so the speaker can be centered approximately
between them. There are several ways to go
about this:
• Use an electronic stud finder. Many stud
finders can also indicate the location of live
AC wiring.
• Tap on the wall and listen to the resulting
sound. When the sound is deeper and more
hollow sounding, you are between studs.
Page 19
