The quality designation SM, or ILSAC
must be on the label.
–30 –20 –10 0 10 20 30 40 50
–20 0 20 40 60 80 100 120
5W-30
qInspecting Engine Oil Level
2.3-liter engine
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal
operating temperature.
3. Turn it off and wait at least 5 minutes
for the oil to return to the oil pan.
4. Open the cap.
5. Pull out the dipstick, wipe it clean, and
reinsert it fully.
Max
OK
Min
6. Pull it out again and examine the level.
The level is normal if it is between
MIN and MAX.
If it is near or below MIN, add enough
oil to bring the level to MAX.
CAUTION
Do not add engine oil over MAX. This
may cause engine damage.
7. Make sure the O-ring on the dipstick is
positioned properly before reinserting
the dipstick.
8. Reinsert the dipstick fully.
9. Close the cap.
Maintenance and Care
Owner Maintenance
8-21
