16
Getti
ng Started
Mounting the Base Station on a Wall
1. Plug the power cord into the back of the base
station and into an electrical outlet.
2. Plug one end of the telephone line cord into the jack
on the back of the base station. Plug the other end
into the phone jack.
3. Line up the tabs on the wall mount bracket with the
holes on the bottom of the base station. Snap the
wall mount bracket firmly into place.
4. Position the base station/wall mount bracket so the
mounting studs fit into the holes on the wall mount
bracket. Slide the base station/wall mount bracket
into place.
