Assembler Messages
Message Codes
MCUez HC12 Assembler User’s Manual
MOTOROLA Assembler Messages 305
12.3.66 A12403: Value Out of Range –256...255
Type: Error
Description: The offset between the current PC and label specified as the PC
relative address is not in the range of a signed 9-bit value
(smaller than –256 or bigger than 255). A 9-bit signed PC
relative offset is expected in these instructions:
• Decrement-and-branch instructions: DBEQ, DBNE
• Increment-and-branch instructions: IBEQ, INE
• Test-and-branch instructions: TBEQ, TBNE
Example:
DataSec: SECTION
var1: DS.W 1
var2: DS.W 10
CodeSec: SECTION
…
LDX #var2
label: LDD var1
CLR 1, X+
dummyBl: DCB.B 260, $A7
DBNE D, label
Tips: Replace the instruction with the following portion of code.
• For decrement and branch:
IFCC Condition
DBNE D, label
SUBD #1
LBNE label
DBNE A, label
DECA
LBNE label
DBNE B, label
DECB
LBNE label
DBNE X, label
DEX
LBNE label
DBNE Y, label
DEY
LBNE label
DBNE S, label
DES
LBNE label
