Monessen Hearth PARLOR VENT-FREE PL20 - Manual (Page 20)

0 90D0093
Parlor Vent Free Fireplace
LG721
PL20 Log 3
Log #3
LG71
Figure 21 -
Place Log #3
3. Place Log #3 by placing rectangular notch on bottom
of log onto the rectangular protrusion on top of log #.
Place the other end of log #3 between the front grate
and the small 'L' shaped bracket located on the right
side of the burner. Allow the end of the log to rest on
the burner. Figure 21
LOG PLACEMENT
LG722
PL20 log 4
LG7
Log #4
Figure 22 -
Place Log #4
4. Place Log #4 by placing rectangular notch on bottom
of log onto rectangular protrusion on front of log #.
Place other end of log between grate bar and rear log
#1 resting log #4 on burner. Figure 22
