Parlor Vent Free Fireplace
LG720
PL20 Log 2
Log #
LG70
Figure 20 -
Place Log #2
LG719
PL20 Log 1
Log #1
LG719
Figure 19 -
Place Log #1
LOG PLACEMENT
. Place Log # on burner by aligning hole in bottom
of log with pin located at front of burner. Gently
push log down until it comes in contact with burner.
Push top of log towards rear placing the rectangular
notch on log # onto the rectangular protrusion on
log #1. Figure 20
LOG PLACEMENT
1. Place Log #1 on burner by aligning
notches on bottom side of each end of log
with the rear corners of the burner. The
light fixture should partially set in cutout
of rear log. Ensure log is sitting firmly on
burner and is locked in where it cannot
slide forward on the burner. Figure 19
