dca220sscu/4i 60 hz generaTor• operaTion manual — rev. #0 (10/25/12) — page 75
fUeL taNk assy.
no. parT no. parT name qTY. remarKs
1 M4363000202 FUEL TANK 1
1-1 0605505070 FUEL TANK CAP 1
2 M4363200004 TANK BAND 2
3 M9310500104 SUPPORTER SHEET 4
4 011008020 HEX. HEAD BOLT 2
5 0207308000 SUPER LOCK NUT 2
6 0191302300 SUCTION HOSE 1
7 Y0191204000 RETURN HOSE 1
8 0605515109 HOSE BAND 4
9 Y0602042579 CART., FUEL WATER SEPARATOR 1
10 014210040 HEX. HEAD BOLT 2
11 Y0602022578 90° ELBOW 1
12 Y0602022985 HOSE JOINT 1
13 0602220911 CLAMP 1
13A 0016906016 HEX. HEAD BOLT 1
14 M1363400104 DRAIN HOSE 1
15 0605515198 HOSE BAND 2
16 1502025103C DRAIN JOINT 1
17 011206020 HEX. HEAD BOLT 2
18 0802011104 DRAIN BOLT 1
18A 0150000018 O-RING 1
