dca220sscu/4i 60 hz generaTor• operaTion manual — rev. #0 (10/25/12) — page 73
MUffLer assy.
no. parT no. parT name qTY. remarKs
1 Y0602300240 DEVICE, AFTER TREATMENT 1
2 M4330400003 BRACKET 1
3 0016910025 HEX. HEAD BOLT 4
4 M2330400704 BAND 2
5 011008020 HEX. HEAD BOLT 2
6 0207308000 SUPER LOCK NUT 2
7 M4333000503 EXHAUST PIPE 1
8 Y0602325039 V-BAND CLAMP 1
8A Y0602320129 GASKET 1
9 Y0602325038 V-BAND CLAMP 1
9A Y0602320128 GASKET 1
10 M3330400804 EXHAUST PIPE COVER 1
11 M3330400903 EXHAUST PIPE BRACKET 1
12 011008020 HEX. HEAD BOLT 4
13 0602326062 U-BOLT SET 1
14 M4333100004 EXHAUST TAIL PIPE 1
15 M4357300014 HARNESS CLAMP 1
16 011008020 HEX. HEAD BOLT 2
17 0601851736 GROMMET 1
18 Y0602311130 EXHAUST INSULATING WRAP 1
19 0605515225 HOSE BAND 4
20 0602220911 CLAMP 1
21 0016910025 HEX. HEAD BOLT 1
