page 12 — dca220sscu/4i 60 hz generaTor • operaTion and parTs manual — rev. #0 (10/25/12)
speCifiCatiONs
Table 1. generator specifications
model DCA220SSCU/ DCA220SSCU4i
Type
Revolving field, self ventilated,
open protected type synchronous generator
armature connection star with neutral
phase 3
standby output 194 kW (242 kVA)
prime output 176 kW (220 kVA)
3Ø voltage (l-l/l-n)
voltage change-over Bd. at 3Ø 240/139
208Y/120, 220Y/127, 240Y/139
3Ø voltage (l-l/l-n)
voltage change-over Bd. at 3Ø 480/277
416Y/240, 440Y/254, 480Y/277
1Ø voltage (l-l/l-n)
voltage change-over Bd. at 1Ø 240/120
240/120
power Factor 0.8
Frequency 60 Hz
speed 1800 rpm
aux. ac power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
dry Weight 6,636 lbs. (3,010 kg)
Wet Weight 7,496 lbs. (3,400 kg)
Table 2. engine specifications
model Cummins QSB7-G6 EPA Interim Tier 4 Certified
Type
4 cycle, water-cooled, direct injection, turbo-charged
air cooled and EGR
no. of cylinders 6 cylinders
Bore x stroke 4.21 in. x 4.88 in. (107 mm x 124 mm)
displacement 409 cu. in. (6.7 liter)
rated output 282 HP at 1800 rpm
starting Electric
coolant capacity 11.4 gal. (43.0 liters) 1
lube oil capacity 4.6 gal. (17.5 liters) 2
lubricating Type oil API service class CJ-4 SAE 15W-40
Fuel Type #2 Diesel Fuel (Ultra low sulfur diesel fuel only)
Fuel Tank capacity 100 gal. (380 liters)
Fuel consumption
12.4 gal. (46.8 L)/hr at full load 9.5 gal. (36.0 L)/hr at 3/4 load
6.9 gal. (26.0 L)/hr at 1/2 load 4.4 gal. (16.8 L)/hr at 1/4 load
Battery 27 (CCA 0°F 800A) X 2
1 Includes engine and radiator hoses
2 Includes filters
