dca220sscu/4i 60 hz generaTor• operaTion manual — rev. #0 (10/25/12) — page 61
CONtrOL BOx assy.
no. parT no. parT name qTY. remarKs
1 M4213000212 CONTROL BOX 1
2 011008020 HEX. HEAD BOLT 14
3 M4213400104 BACK PANEL 1
4 M4213500104 TOP PANEL 1
5 011008020 HEX. HEAD BOLT 16
6 M4260500103 SET PANEL 1
7 011008020 HEX. HEAD BOLT 4
8 Y0602201456 MAGNETIC SWITCH 1
9 Y0602201457 MAGNETIC SWITCH 1
10 0016906016 HEX. HEAD BOLT 4
11 0601821370 RECTIFIER 2
12 0027104020 MACHINE SCREW 2
13 LY2DUS24VDC RELAY ...............................................................1................REPLACES P/N 0601827655
13A PTF08A RELAY BASE .....................................................1................REPLACES P/N 0601823109
13B PYCA1 RE LAY CLIP .....................................................1................REPLACES P/N 0601824400
14 0027104020 MACHINE SCREW 2
15 Y0601872130 HOLDER, FUSE 1
15A Y0601806603 FUSE,150A 1
16 0601815153 TERMINAL BLOCK 1
17 0027104020 MACHINE SCREW 2
18 0601802218 HOLDER, FUSE 1
18A 0601806671 FUSE (LEFT), 15A 1
18B 0601802131 FUSE (CENTER), 1A 1
18C 0601802133 FUSE (RIGHT), 5A 1
19 0027103020 MACHINE SCREW 2
20 0601809667 CURRENT TRANSFORMER 3
21 0027106020 MACHINE SCREW 6
22 Y0801820847 OVER CURRENT RELAY 1
23 0601820848 OVER CURRENT RELAY 1
24 0027104020 MACHINE SCREW 2
24A OEMAA8 HEX. NUT 2
25 Y0601807523 CIRCUIT BREAKER, 3P 600A 1
25-1 Y0601827412 REAR TERMINAL BUSBAR 2
26 014210040 HEX. HEAD BOLT 6
26A 021112140 SELF-LOCKING NUT 6
27 0601820604 AUTOMATIC VOLTAGE REGULATOR 1
