4-7
System Reso urces
SB600 GPM Config.
SB600 EXTEVENT & GEVENT Config.
GP M Pi n Type Multiplexed Power Function
GPM#0 I/O(S5_3.3V) USB_OC0# Standby USB OverCurrent
GPM#1 I/O(S5_3.3V) USB_OC1# Standby USB OverCurrent
GPM#2 I/O(S5_3.3V) NA Standby NC
GPM#3 I/O(S5_3.3V) NA Standby NC
GPM#4 I/O(S5_3.3V) NA Standby NC
GPM#5 I/O/OD(S5_3.3V) NA Standby WLAN_PWRON
GPM#6 I/O(S5_3.3V) NA Standby GPM6#
GPM#7 I/O(S5_3.3V) SYS_RESET # Standby SYS_RESET#
GPM#8 I/O(S5_3.3V) NA Standby NC
GPM#9 I/O(S5_3.3V) NA Standby NC
GEVENT P in Type Multiplexed Power Function
EXTEVENT0# I/O(S5_3.3V) NA Standby NC
EXTEVENT1# I/O(3.3V) NA M ain NC
GEVENT2# I/O(S5_3.3V) NA Standby NC
GEVENT3# I/O(S5_3.3V) LP C_PM E# Standby LPC_PME#
GEVENT4# I/O(S5_3.3V) PCI_PM E# Standby PCI_PME#
GEVENT5# I/O(S5_3.3V) NA Standby NC
GEVENT6# I/O(S5_3.3V) NA Standby NC
GEVENT7# I/O(S5_3.3V) NA Standby NC
GEVENT8# I/O(S5_3.3V) PCIE_WAKE# Standby PCIE_WAKE#
