MSI AM-690E User Manual
Page 21
2-3
Hardware Setup
CPU (Central Processing Unit)
Important
1. Overheating will seriously damage the CPU and system. Always make
sure the cooling fan can work properly to protect the CPU from overheating.
2. Make sure that you apply an even layer of heat sink paste (or thermal tape)
between the CPU and the heatsink to enhance heat dissipation.
3. W hile replacing the CPU, always turn off the power supply or unplug the
power supply
’s power cord from the grounded outlet first to ensure the
safety of CPU.
When you are installing the CPU, make sure the CPU has a heat sink and a
cooling fan attached on the top to prevent overheating.
If you do not have the
heat sink and cooling fan, contact your dealer to purchase and install them before
turning on the computer.
