MSI AM-690E User Manual
Page 54
3-22
MS-9826 Mainboard
South Bridge Configuration
USB 1.1 OCHI Controllers, USB 2.0 EHCI Controller
This settings allow you to enable/disable the onboard USB1.1/ 2.0 controller.
OnChip SATA Channel
This item is used to enable/disable the onboard SATA channel.
OnChip SATA Type
This setting specifies the operation mode of the SATA drives.
