2 RASCard Description
CommPlete Communications Server 11
LED Indicator Color Indication
RAI ALARM Red Also known as RAI (REMOTE ALARM INDICATION).
On indicates that the E1 card is receiving unframed all 1s,
indicating disconnection or attached device failure.
Off indicates that the attached device is operating correctly.
TEST MODE Red On indicates that the E1 card is in one of several possible test
modes.
Off indicates that the E1 card is not in a test mode.
Switches
Power Switch
The power switch turns the RASCard on and off. An LED indicator in the switch lights
when the RASCard is on.
Reset Switch
The reset switch is a momentary push-button that is recessed behind a small hole in
the front panel. It provides a hardware reset (hard boot) for the CPU should it become
locked up. Use a straightened paper clip or similar device to activate it.
